Shantui SE215W 22Ton Excavator

• Price : $82,857.00
Engine:
Model: Weichai WP7H
Type: High pressure common rail, turbocharged
Number of cylinders: 6
Emission: Tier 4/Stage IV
Displacement: 6.8L
Power output: 140kW/2000rpm
Hydraulic System:
Type: Axial variable plunger pump
Max.    discharge flow: 2x225L/min
Digging Force (ISO6015):
Bucket: 148kN
Arm: 107kN
Bucket:
Type: Backhoe bucket
Capacity: 0.45 - 1.2(1.0)m³
Width: 1314mm
Travel System:
Type: Axial variable plunger motor
Track roller: 2x8
Carrier roller: 2x2
Track shoe: 2x47
Travel speed: 3.7/5.7km/h
Max. Drawbar pull: 212kN
Gradeability: 70% (35)
Swing System:
Swing motor type: Swash plate plunger motor
Swing speed: 0 - 11.0r/min
Brake type: Pressure release mechanical braking
Refill Capacities & Lubrications:
Fuel tank: 330L
Cooling system: 28L
Engine oil: 22L
Hydraulic oil tank: 270L
System Capacity: 400L
Operating Weight and Ground Pressure:
Shoe width: 600mm
Ground pressure: 48.6kPa
Operating weight: 22200kg
Scope of Work:
Max.  digging height: 10100mm
Max.  dumping height: 7190mm
Max.  digging depth: 6490mm
Max.  vertical digging depth: 5770mm
Max.  depth cut for 2500mm level bottom: 6295mm
Max.  digging distance: 9865mm
Max.  digging radius at ground level: 9680mm
Min. swing radius of work equipment: 2970mm
Dimensions:
Overall length: 9610mm
Ground contact length (Transportation): 4965mm
Overall height (to top of boom): 3040mm
Overall width: 2980mm
Overall height (to top of cab): 3100mm
Counter weight ground clearance: 1180mm
Ground clearance: 470mm
Tail swing radius: 2980mm
Tread: --
Track length: 4270mm
Track gauge: 2380mm
Track width: 2980mm
Shoe width: 600mm
Bonnet height: --
Revolving frame width: 2725mm
Distance from swivel center to tail: 2910mm.
