Emission Standard: Euro 4
Work quality: 16400 kg
Maximum unloading height: 3377 mm
Unloading distance: 1040 mm
Maximum digging force: 170 kN
Three-term sum: 9.7 s
Engine:
Model: WP10H
Rated power/Rated speed: 162/2000 kW/rpm
Overall dimensions: 8180x3028x3425 mm
Walking performance:
Forward speed: 0 - 40 km/h
Backward speed: 0 - 16.3 km/h
Chassis system:
Wheelbase: 3000 mm
Fuel tank capacity: 251 L
Working device:
Rated bucket capacity: 3 m³
Rated load capacity: 5 t.
