Cooking oil transport semi-trailer

SPECIFICATIONS:
Cooking oil transport semi - trailer
Dimensions and Volume
Installation dimensions:12755×2498×3850mm
Cargo van size: --
Tank material: Aluminum and magnesium alloys
Effective volume of tank: 46.2 cubic meters
Overall dimensions of tank: --
Transport medium: Cooking oil
Medium density: 0.76 t/m³
Weight-related
Total vehicle mass: 40000 kg
Rated load mass: 33500 kg
Curb weight: 6500 kg
Fifth wheel maximum loading capacity: 16000 kg
Axle weight: -/8000/8000/8000
Vehicle Configuration
Chassis model: --
Number of axles: 3
Wheelbase: 7010 + 1360 + 1360mm
Number of tires: 6
Super - single tire size: 425/65R22.5
Wheel track: 2040 mm
Fuel type: Cooking oil
Air suspension: Optional
Body color: Aluminum alloy color
Vehicle brand: Ming navigation brand
Other Information
Close/Angle of departure: -/21(°)
Rear overhang: -/1490(mm)
Top speed: --
Side protective device materials: Aluminum alloy
Connection method: Bolt connection
After the lower protective device materials: Aluminum alloy
Connection method: Bolt connection, Section size 140 x 120 mm, Height 520 mm from the ground
ABS manufacturer: WABCO company
ABS model: 4005000810
